Fig. 122. has a tendency to depress the point of the tool a little, bringingit, wliUe cutting, nearly to the center. The amount the tool isset above the center is slight, and of course depends upon thecharacter of the work. The angle A C B, Fig. 121, should beonly about 5 or 6 degrees. 82 MACHIJSE…
