is usually graduated on the inner edge, and the other on theouter edge. The flat square is not hardened. The try square, shown in Fig. 10, consists of a beam anda blade at right angles. The beani is much thicker than the … Fig. 8 blade and somewliat shorter. Try squares aio made both un-hardened and hardened. The unhardened foi-m has graduationson one edge, and is called the graduated try square. Tiie hardened type always has a hardened blade, sometimes a hardenedbeam as well, and is not graduated. MACHINE SHOP WOKK.…
