the floor, though the weight of the machine maybe sulhcieiit to hold it in position. On the left-hand end of thehed there is fastened the head stock B, which carries the mainrunning gear of the machine. At each end of the head stocktlicre is a bearing for the spindle. Running loosely on the… … Fig. 90. gear is more clearly slio\\ u in Fig. 92. The large gear E aloneshows in Fig. 91. It is driven by the pinion D which is attachedto the cone. The pinion on the same sleeve as the gear E drivesthe gear at the right of the cone. This gear is keyed to thespindle. When the back gear is not in…
