hey are called, are usually madewith a solid web instead of arms, and are glued up in solid blocksof end wood, the grain of the entire block running parallel with the |face of the teeth. Such an end wood pinion is shown in Fig. 243. jIt is turned and the gear laid out and cut in the same way as… … Fig. 2i.3. . 146 PATTERN MAKING 13J5 after being shaped and finished, from the face of each tooth intothe rim. Patterns for Bevel Gears are built up as illustrated at «,Fig. 244, the wooden face-plate, or chuck, being provided with tenor more radial blocks as shown and described in Fig. 168.…
