?rn on mo/c/ hoarc/ Fig. 44. SpUt and Loose-Piece Patterns. B .shows the drag parts of the patterns in position for molding. AtC is the .section through the mold and the plan of the drag showinghow the gates are connected. Attention is directed to the use of the)ioTn sprue—the sprue pattern is…
