Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 32

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 32
o the work with one heavy blow:and this is esix3cially the case if the saw is hard, as all good andwell-tempered saws should be. The back saw illustrated in Fig. 18 is used as a bench saw forliglit or fine work, and for fitting and dovetailing. Saws of thistype are made from 8 to 11 inches in… … 17. Fig. 19. same as already described for hand saws. At least two back sawswill be found necessary, one filed for crosscutting, and the otherfiled as a rip saw for cutting icith the grain of the wood, as inthe cutting of tenons and dovetails. EXERCISE. While for those who have had experience in…

Mechanical engineering -- Dictionaries

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
