is used in many different forms of clutches. Friction Clutches. A jaw clutch such as illustrated in Fig.22, if thrown in while the shaft or gear is turning brings a suddenshock on the parts, which is likely to cause damage, especially ifthe speed is high and much power is transmitted.… … Fig. 22. trates a simple clutch of lliis kind. B is a piece free to slide on akey, and held in position by a shipper. A is a pulley or gear looseon the shaft. The outer surface of B and the inner surface of Aare tapered to fit each other. When B is thrown to the left itclamps A to the shaft in the…
