Ke as a diameter, drawa semicircle and divide this semicircle into as many equal parts aswe divided the arc AIIE in Figs. 35 and 36. From the points 344 MECHANISM. 37 P.CT), etc. (Fi<r. 37), draw perpendiculars to line A^, cnttinrr itat points 1, 2, 8, etc. The division A-1, 1-2, etc., thus… … to be (irravitY Since Ae is to be divided into as many equal})arts as arc AIIE, in this case it will be divided into eight parts.Now if the motion which the cam is to give to piece P is to beuniformly accelerated and retarded (that is, gravity motion ), Aemust be divided in such a way that the…
