may be said to be the limiting case of the linkageshown in Fig. 48. This is the linkage which we have in the crank,connecting rod, crosshead and crosshead guides of a steam engine.The crank shaft corresponds to the pin A, the frame and guides 352 MECHANISM. 45 take the place of the slotted link AC,… … Pig. 48. Fig. 50 shows the same linkage, the links being representedby their center lines only. AD is the crank, DC the connect-ing rod, C the crosshead and AC the center line throuo-h the crankshaft and the guides. Suppose the crank has a length K and is making N rt-volu-tions per minute at a…
