heavynormal force or pressurebetween surfaces at sucha radius from the drivenaxis, that the product ofthe force of frictionthereby created and theradius shall equal thedesired twisting momentabout that axis. Three ty[)ical meth-odsof accomplishing thisare shown in Figs. 48,49, and 50. None ofthese… … MACHINE DESIGN 141 sible way, an absolutely direct push being exerted between thediscs, due to the thrust P of the clutch fork. In Fig. 49 advantage is taken of the wedge action of the; in-clined faces, the result be-ing that it takes less thrustP to produce the requirednormal pressure at the…
