no. laaB. Fig, 489. Fig. 490. 332 ROGERS DRAWING AND DESIGN. … This lathe may be fed by a friction feed or bythe lead screw. Slightly below and midway betweenthe shears in the bed, passes a splined shaft, whichdrives the tail stock face plate by means of an inter-mediate gear, shown in Fig. 490. This small gearcan be thrown out of action by the worm-wheel…
