Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 130

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 130
face the machineat the delivery, or doffer, end and whichever side the driving pul-ley is upon decides the question. Fig. 61 shows a right-handcard. Upon the leader is a pulley, B, driven from a large pulley,D^, which is upon the cylinder shaft, by the crossed belt, E. Thedoffer comb is driven from… … W fee The flats, B-^, which pass slowly over the cylinder in thedirection indicated by an arrow, are driven from a sprocket wheel 116 COTTOX SPINNING. 79 which is fastened to the inside of the front block, Wi. Motionis communicated to the latter from the small pulley, C, \Adiich is

Textile fabrics · Textile industry
