The flats, B, wluch pass slowly over the (.-vliudei in tUedirection indicated by an arrow, are driven from a sprocket -wheel COTTOX SPINNING. which is fastened to the inside of the front block, Wi. Motionis communicated to tlie latter from the small pulley, C, which is … upon tiie cylinder shaft, by the belt, W, the pulley, A^ theworm, J, the worm gear, F, the worm, U, and the worm gear so COTTON SPINNING. A.i, which is upon the front block shaft. The usual speed of thefiats is about three inches per minute. The stripping brush is driven from a groove on the inside…
