Locomotive engine running and management .. (1899)
Sinclair, Angus, 1841-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 41
ansion link, back half. 8. Expansion link, front half. 9. Expansion-link filling-block. 10. Expansion-link saddle. 11. Expansion-link sliding-block. 12. Link-hanger. 13. Tumbling-shaft, 14. Counterbalance-spring. 15. Tumbling-shaft bracket. 16. Reach-rod. 17. Upper rocker-arm. 18. Rocker-box. 19.… … IN TR OB UC TION. XXIX nected with the running of locomotives, for a great partof the failures that happen to modern locomotives arisefrom accidents to some part of the running gear. By referring back to Plate B, it will be seen that theframes, driving-wheels, and truck with their minor partsform a…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
