359 64 KNIT GOODS FINISHING The mechanism for driving the cloth-feed rolls, of which 31 is one,is as follows: 21, 22 and 23 are sprocket-wheels fast to the main shaft.21, 22, and 23 are corresponding sprocket-wheels fast to the … connter-shaft 24. 45 is the sprocket-chain, by shifting which fromone pair of said sprocket-wheels to another the speed of the counter-shaft 24 may be varied with respect to the speed of the napping-cylinder. 25 is a pinion fast on the shaft 24 and which drives a gear 360 KNIT GOODS FINISHING 65…
