Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School of Correspondence · Chicago, American School of Correspondence · leaf 342
er as on the ring frame. An elevation of the mule carriage is shown in Fig. 222 and aplan of the gearing, in Fig. 223. The spindles, L% and the drum,C°, are in the carriage, E, which.moves back and forth in a horizontaldirection upon tracks, E, which are called carriage tracks. 807 266 COTTON… … commence to turn and at the same instant, the carriage begins itsoutward run and the yarn, being delivered by the rolls, is kept undera slight tension and is twisted; when the carriage reaches the end of COTTON SPINNING its outward run, or stretch, which is about sixty-four inches, it isstopped and…
