haft through the gears of fifteen, nineteen, thirteen and thirty-eight teeth. On the lower end of the drawing-up shaft, S, is the drawing-up 322 COTTON SPINNING 281 friction, P, which rotates with the shaft. The bottom of the friction,T, upon wliich is the bevel gear of thirteenteeth, is mounted… … Fig. 334. Elevation Showing Carriage Shaft Clutch. up friction, P, engages with the lower part, T,and the carriage is drawn in. The scrolls, Aand B, serve for this purpose, while the scroll,C, acts as a check upon the carriage. Thescroll band unwinds from C while the otherbands are winding around A…
