Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 327

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 327
1305. V-GROOVED FACE CLUTCH.—A very effective clutch with teeth of smallangle. … 1306. CLUTCH AND GEAR.—The clutch slides on the feathered shaft, andthrows the gear into motion by the operationof the bell-crank lever and runner. MILL AND FACTORY APPLIANCES. 321

Mechanical movements
