Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 56

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 56
eries ofl)lows is given, by which the cotton is stripped or beaten from thepins and thrown against a screen or grid directly beneath thedoifer, called the doffer screen, through which any loose dirt willfall. Beneath the doffer scieen is a dust drawer, G, which ]-eceives(Inst and dirt tliat is… … The cotton is next carried forward by tlie feed ajiron, pass- 48 COTTON SPINNING. 13 ing under the press roll, L, to the feed rolls, N. The press rollcondenses the cotton, that it may be drawn readily between thefeed rolls, which, being small in diameter, could not receive it in aloose form. After…

Textile fabrics · Textile industry
