Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 59

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 59
series ofblows is given, by which the cotton is stripped or beaten from thepins and thrown against a screen or grid directly beneath tliedoffer, called the doffer screen, through which any loose dirt willfall. Beneath the doffer screen is a dust drawer, G, which receives(lust and dirt that is… … o The cotton is next carried forward by tlie feed apron, pass- 48 COTTON SPINNING. 18 ing under the press roll, L, to the feed rolls, N. The press lollcoudeiises the cotton, tli;it it may be drawn readily between thefeed rolls, which, being smull in diameter, could not receive it in aloose form.…

Textile industry · Textile fabrics
