American School of Correspondence · Chicago, American school of correspondence · leaf 168
^—--^ Fig^ 95. Section Showing Flat Grinder. … Fig 96. Position of Flat before Grinding. ing roll, equal to the difference in the height of the bearing surfacebetween the heel and toe of the flat. 147 110 COTTON SPINNING. In Fig. 96, the flat is shown advancing towards the grindingroll with the wire face at an angle. Fig. 97 shows the flat…
Textile industry and fabrics
