Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 351

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 351
n of all the necessaryparts from the position, occupied during the outward run, to the posi- 311 270 COTTON SPINNING tion wliic-h they are ()l)lige(l U) assume (luring winding. The mechan-ism is shown in Figs. 224, 225 and 226. At the end of the outward run, the carriage shaft chitch, H^, isthrown… … FiR. 224. Detail of Cam Shaft. spinning. This unwinds the few coils of yarn that are aroinid thespindle between the top of the cop and the point of the spindle. Thewinding faller, K, which acts as a guide for the yarn, is brought downinto position and the counterfaller, K^, ascends, until it meets…

Textile industry · Textile fabrics
