A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 140

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 140
22 toraise said jack. A vertical wire 23 is supported atits lower end in the recess in the lever 19, and en-gages at its upper end the upper hook jack 1. Fast on the upright driven shaft S is a cam 24,which has a cam groove 25 therein, into which ex-tends and travels a roll on a pin 26, on a lever… … Fast on the rock shaft 28 is the lower end of anarm 31, which has a projection 32 at its upper end,adapted to engage recesses 33 in the lever 34, faston the rock shaft 15. A spring 35, attached to thelever 31 and to the frame, holds said lever 31 inengagement with the recesses in the lever 34.…

Textile fabrics · Textile industry · Textile machinery
