Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 135

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 135
. The feed sheet moves | x ff X 2|- X V = f inches perminute. But the cam 0 (Eig. 68) which opens the pan P by meana 113 102 WOOLEN AND WORSTED SPINNING of lever L, is also driven direct from tlie feed roll, through the samegears, 25 and 28, and a chain over two sprocket wheels of 11 and13 teeth.… … Fig. 68. 8 J-g- inches, and if the pan always contains one-half pound of wool,it follows that every 8yL- inches of feed sheet must always becovered by one-half pound of wool. In this, the whole principle ofthe machine is embodied. The mechanism for filling the pan is quite simple. Thesheet G is…
