he socket gear to the differential motion. Asthe bobbin is being filled the bevel is always changing, owing to theinfluence of the lifter, thus making it necessary to mount the con-necting gears between the socket gear and bobbin shaft gear in sucha manner that the continuity of motion shall be… … gear is mounted in a swing. S is the driving gear, J the intermediate,and B the bobbin shaft gear. The stud upon which J works is sup-ported in a curved bracket with a slot to allow for the movement caused by the lifter. This method isobjectionable because the speed in-creases as the lifter…
