Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)
Chicago : American school of correspondence · leaf 63
Fig. G2. half of the warp can he alternately raised for the passage of tlieshuttle. The warp is kept in tension by means of weights connected … Fiff. 63. to a rope [)assing once or twice round the warp beam. The clothbeam is provided with a ratchet wheel and pa\\l ^I, also with ahandle Z, for winding on the cloth as it is woven. In Fig. 6-1 only one each of the leeses is shown, but as 61 44 TEXTILE DESIGN. there iniist be one to each pair…
Textile industry · Textile fabrics
