Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 223

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 223
e pin gear motion, derivmg its namefrom the manner of driving the large segment or space gear, B, 193 180 WEAVING The pill gear, also termed the clog, is attached to the end of thepick cam shaft, and as the shaft revolves, the pin. A, enters one ofthe recesses in the segment gear, B, advancing the… … Fig. 117. Lower Box Motion, advancement of one space has the value of seven teeth. Thesegment gear revolves on a stud fixed to the frame, about 3iniches forward of the pick cam shaft. At the top and side of thesegment gear, small shafts, C C, are placed, carrying at one endcams, which operate the…

Textile fabrics · Textile industry
