Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 272

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 272
mcircular to reciprocal knitting and vice versa is to be made by the pat-tern wheel. The outer end of the clutch lever D^ (Figs 138 and 139) is forkedto embrace the wheel C% each fork being provided with sliding pins 340 KNITTING 223 a^ and a^* (See Fig. 140), each pin having at or near one end a… … Fig. 139. The bar a^^ has connected to it a lever pivoted at D^^ and havingconnected to it a link slotted at one end to embrace and slide on a screwstud carried by a change lever o}^ (Fig. 141) with three arms, andbeing pivoted on a stand attached to the bed. The change lever aP is acted upon its…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
