stem outside the plate has feather-splined on it a gear ?i*, whichis kept on by the screw n. The gear meshes into the rach n^, whichis connected to the slide block ?^^ fitted into the guideway n^ of theplate N. When the rack is moved up it turns the gear on the stem ofthe switch and sets it in… … finished, to lead down all the needles previously lifted, and then to beraised in circular knitting. The rack has a cam face at one side, with which co-operates alocking device ?/, which serves to hold the rack in position as left byits actuating device. When the narrowing in the heel and toe…
