Dental and oral radiography : a text book for students and practitioners of dentistry (1916)
McCoy, James David · St. Louis : Mosby · leaf 69
Fig. 25.Diagram of an x-ray tube. side of the elongation, and also serves as an elec-trical connection. The concave reflector is known as the cath-ode and the metallic block opposite it and lo-cated upon the end of the sheet iron tube is knownas the target or anode. Above the anodeand at an angle… … REQUISITES OF DENTAL X-RAY LABORATORY 67
Radiography, Dental · X-rays · Teeth · Mouth
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
