Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 103
engines, the length of thepiston-pin is almost invariably one-half the diame-ter of the cylinder and the diameter of the pin 0.15 to0.25 the diameter of the cylinder. This leads to pres-sures of 1,800 to 2,200 lbs. per sq. in. of projectedarea. 42 OIL ENGINES. Medium power and large engines have… … Fig. 21.The Engine Frame.—Different designs of engineframes are shown in the illustrations of sectional views Gas Engine Design by C. E. Lucke, Ph.D.
Internal combustion engines
