Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 283
Fig. 77a. being placed on the side of the engine. The air inletin this type is different from the other engines de- 184 OIL ENGINES. scribed. In this case the air enters not through the va*porizer, but by means of separate valve-chamber. … Diagram taken from Hornsby-Akroyd Engine: M. E. P., 48lbs.; compression pressure, 50 lbs.; maximum pressure,160 lbs.; revolutions per minute, 185; cylinder, 18.5diameter; 24 stroke; full load.
Internal combustion engines
