thesectional view.) The journal sleeves shown in the engraving are of the self-aligning type,but if the reader is not verv skilful at machine tool work .it will be pref- SELF-STARTING SINGLE-PHASE INDUCTION MOTOR 129 erable to make them perfectly straight, making the outer diameter of thesleeves f… … FIG. 162 THE ROTOR The rotor is shown by Fig. 162. It consists of 108 discs of sheet steelclamped on the shaft between two cast-brass end plates, which also serveto connect the ends of the rotor conductors. There are 17 of these, each| in. in diameter and 4 ins. long; the holes in the rotor discs…
