relatively tothe center of eccentric until the angle included between their respectivecenters is as determined by the calculation given; in the example, 81 de-grees 34 minutes, the eccentric leading the crank in the direction of motion.After the valves have been set as accurately as possible when… … 196 VALVE SETTING For single-stage air compressors and in the high-pressure cylinders oftwo-stage air compressors the Allis-Chalmers Company, of Milwaukee, usesas a standard the arrangement of valves shown in Fig. 196. Eotary valvesare used for the inlet and plain single-beat poppet valves for the…
