A dictionary of electrical words, terms and phrases (1898)
Houston, Edwin J. (Edwin James), 1847-1914 · New York, The W. J. Johnston company · leaf 340
Fig 3Si Series and Magneto Dynamo. Machine, Dynamo-Electric, Series andSeparately Excited A compound-wound dynamo-electric machine in whichthere are two separate circuits on the fieldmagnet cores, one of which is connected inseries with the field magnets and the exter-nal circuit, and the other… … R R R .vV^Jfe 4£- -S^ ^-C. Fig. 332. Series and Separately Excited Dynamo. This machine is employed for maintaining aconstant potential at its terminals. Machine, Dynamo-Electric, Series andShunt Wound A compound-wound
Electricity · Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
