Dynamos and motors; a text book for colleges and technical schools (1911)
Franklin, William S. (William Suddards), 1863-1930, Esty, William, 1868-1928 · New York The Macmillan company · leaf 61
Fig. 28. Wheeler Company. This dynamo has a ring-wound armature,the details of which are shown in Fig. 29. Figure 30 is a general … Fig. 29. view of a multipolar direct-current dynamo manufactured by theFort Wayne Electric Works. The field yoke is cast in two parts. * Motors are now usually enclosed and a general view of such a motor would shownothing but an iron bo.x. THE DYNAMO AND THE TRANSFORMER. 51
Dynamos · Electric motors
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
