Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 457
ingelliptical curves. This moulding can best bedescribed by the use of a trammel, an instrumentI will describe later on; or the curve may beobtained by the use of the ellipsograph, shownin Fig. 18. 76 ARCHITECTURAL DRAWING SELF TAUGHT These examples will fully suffice to give thelearner good… … Fig. 67.burden this work with examples and instructionsthat the ordinary draftsman or workman maynever be called upon to make use of. One of the simplest methods of forming anellipse is by the aid of two pins, a string and alead pencil as shown at Fig. 68. Suppose F Bto be the major or longest…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
