Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 573
tion with the squareis shown in finished work at Fig. 177. Thisrepresents a perforated balustrade or parapet;the curved lines are obtained by the compass,centers being easily found. 168 ARCHITECTURAL DRAWING SELF TAUGHT A Still more complicated figure is shown atFig. 178. This may be formed as… … Fig. 178. which may be done as in Fig. 179, by forming asquare, and thereafter an octagon the side ofwhich is equal f e, f g. Draw lines, I i m, distantfrom each other equal to the distance betweenthe rhomboids in Fig. 178. Parallel to thediagonal lines c b, a d, draw lines equal to i i,From e, one…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
