Educational woodworking for home and school (1908)
Park, Joseph C · New York, MacMillan · leaf 54
Fig. 13. — Level glass(showing setting). Fig. 14. — Plumb glass (showing setting). 14. Marking Gauge. — The marking gauge (Fig. 15)is used in drawing a line parallel with a straight edge.The parts are called the bar, head, thumbscrew, and point. The barhas graduationsin inches. Thehead and barare… … Fig. 15. — Marking gauge, a, bar; 6, head;c, thumbscrew; d, point. 36 EDUCATIONAL WOODWORKING
Manual training · Woodwork
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
