count n the number of surface conductors ineach phase. In the second case, Fig. 11, the E.M.F. between either THE E.M.F. OF DYNAMOS AND MOTORS. 159 A or B and the common line C, that is, the machine E.M.F.will be n E = 2.2 2(f)- Vp 2 1.11 <$>nf 10 10 This is the same as the first case. But… … Fig. 12. If the current in each circuit as measured by an alter-nating current ammeter placed in the wire A or B be /,then the current in the common wire C is the geometricsum, or resultant of the two equal currents at right angles ;namely / = V2 X L This assumes the circuits to beproperly…
