International Library of Technology · Scranton, International Textbook Co. · leaf 238
ssure which would be given by the voltmeter V, and itis the resultant sum of the E. M. F. to overcome resistance (1,000 volts)and that to overcome reactance (884 volts). 3911. In ail alternating-current circuit as consideredin the above example, it is thus seen that it is quite possiblefor the… … triangle being laid off to scale to represent the differentE. M. F.s. CIRCUITS CONTAIIVING RESISTANCE, SELF-INDUCTION, AND CAPACITY. 3912. It quite frequently happens that a circuit maycontain all three of the above. Electrolytic cells in some casesact like a condenser, and synchronous motors under…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 238](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-238-123.webp)
