types of alter-nators. This arrangement is shown in Fig. 1512, except CURRENT APPARATUS. 2651 that in this case the machine is provided with eight radialpoles and eight coils on the armature, giving a style of wind-ing in common use for machines used on lighting circuits.In this case there are as… … Fig. 1512. alternators, and the designer has to select the one best suitedto the work which the machine nas to do. In Fig. 1512 thecoils Care shown bedded in the slots/ on the circumferenceof the iron core P, which is built up of thin iron stampings.These coils are heavily taped and insulated and…
