International Library of Technology · Scranton, International Textbook Co. · leaf 264
Fig. 40. … Fig. 41. operation of the Westinghouse device will be understoodby referring to Fig. 41. L, L, L represent a series of ELECTRIC LIGHTING. 67 ten lOOvolt lamps connected across the 1,000-volt mains M.Across the terminals of each lamp a coil c, wound on alaminated iron core d, is connected so that…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 264](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-264-153.webp)
