Fig. 53. collector rings mounted on the shaft. By means of theserings the exciting current is led into the field. The stationaryarmature windings f, f (in this case shown for a single-phase 90 ELECTRIC LIGHTING. 16 machine with two slots to each pole) are held in groovesaround the inner periphery… … and this core is supported by the casting L, also shown inFig. 52, attached to the base of the machine. The terminalsof the stationary winding are shown at M, Fig. 52. The § 16 ELECTRIC LIGHTING. 91 whole armature structure is arranged so that it may beslid along on the base so as to give access to…
