An elementary book on electricity and magnetism and their applications (1919)
Jackson, Dugald C. (Dugald Caleb), 1865-1951, Jackson, John Price, b. 1868, Black, Newton Henry, b. 1874 · New York, The Macmillian Co · leaf 375
resistance, as de-scribed in section 225. Thisis illustrated by the diagramin figure 234, where the re-sistance is represented bythe horizontal line OR, thecapacity reactance by OC,drawn vertically downward,and the inductive reactanceby OL, drawn upward. Thenby subtraction, the resulting reactance… … Fig. 234. — Diagram to show how tocompute impedance in a circuit con-taining resistance, inductance, andcapacity. INDUCTANCE AND CAPACITY 345 For example, suppose a circuit contains 25 ohms inductive react-ance in series with 70 ohms capacity reactance and 40 ohms resistance.What is the impedance?…
Electricity · Magnetism
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
