Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 236
known asone ring; 3—follower; 4—ball joint; 5--swab cup;6—vibrating cup; 7--gland; 8—preventer; 9--sup-port. LOCOMOTIVE APPLIANCES.JEROME METALLIC PACKING. 227 Fig. 1 represents the Jerome piston rod packing,embracing all the new improvements used therewith.The parts designated by letter are:… … Fig. 1.Jerome Piston Rod Tacking. holder; N -swab holder; M- the swab. The swabholder N is one of the best devices for oiling the pistonrod and valve stem of an engine vet invented, and isnow applied to all of the Jerome packing. Fig. ,? shows in detail the Jerome standard pistonpacking for rods…
Locomotives
