Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship (1893)
Langmaid, Joseph, Gaisford, H · London, New York : Macmillan · leaf 217
Fig. 85.—Section of Double Ported Slide Valve. (Page 19;.) … Fig. 83.—Piston Slide Valve. (Page 19t3.197 lesson xx PISTON AND SLIDE VALVE L99 Slide Rod Guides.—The rods for working slide valves areusually fitted to work in guides, the bracket seen at hack ofpiston rod in Fig. 82 is fitted to hold the slide rod guide Detachable Voire. Face* on Cylinders.—The…
Steam-engines · Marine engines
