Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 188
ton-rod end of the cylinder of any locomotive or other steam-engine, and which, by means of the stout block, called a cross-head, sliding between them, constrain the piston-rod, which isfastened to the cross-head, to move in a straight line. 3. The working parts are connected together, forming a…
Geometrical drawing · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
