Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 193
here as a sufficient guide; the object, more-over, being symmetrical with respect to the centre line 00, anda little more than half shown. Description.—BB, not definitely shown in plan, is a portionof the main bed of an engine. SS is the sole of the pillow-block, DD its body, CC its cover, and… … SUPPORTERS AATD CRANK MOTIONS. 117 of the bolt. This construction allows for adjustment of theposition of the block by wedges, driven between the sole andstops I, solid with the bed B. The cover CO is held in place by bolts c—cW, the heads hrbeing in recesses, sunk in the under side of the sole.…
Geometrical drawing · Mechanical drawing
