minium pointer moves over a graduated scale andmirror indicating, when the coil is deflected, the E.M.F.in volts. A similar instrument is designed for giving by directreadings the Talue of the currents in amperes or milli-amperes. In these ammeters the movable coil onlycarries a small fraction of… … Fia. 76.—Coils and connections of the megger. high resistance it Avould reduce the strength of the currentwhen placed in the circuit, consequently the coil iswound to a fraction of an ohm. But a voltmeter is alwaysjoined as a ^liunt to the circuit Avhere a measurement isdesired, and has a very high…
